OGMA 36mm Unmounted UV/IR Cut Filter
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available.
- This item is out of stock.
- We have no ETA from the manufacturer at this time.
- Sign up for back-in-stock alerts to be notified when this item becomes available.
Lower 48 States:
Orders over $50 ship free within the Lower 48 using a carrier and service we select based on your items and delivery location. Faster shipping options may be available at checkout.
U.S. Outside the Lower 48 (AK, HI, PR):
Free shipping on orders over $50 applies to many—but not all—items. Add items to your cart and enter your ZIP code to see available shipping options and any costs.
International Orders:
Free shipping does not apply to international orders. You’ll see available shipping options and costs during checkout. Some items can’t be shipped internationally due to size or manufacturer restrictions. Duties, taxes, brokerage fees, and tariffs are not included and are the customer’s responsibility.
The ideal luminance (UV/IR) filter for 36mm filter wheels.
This filter is unmounted; it doesn't have a metal ring.
The blackened edge of this filter helps reduce reflections and stray light, improving contrast and preventing unwanted artifacts in imaging applications.
Transmission
The following emission lines that are important for astrophotography are passing at > 95%.
- Hydrogen Alpha (H-Alpha): 656nm
- Sulphur II (SII): 672nm
- Nitrogen II (NII): 654nm and 658nm
Specifications
- Diameter: 3mm
- Edge treatment: Blackened
- Physical thickness: 1.85mm
- UV cut off: < 400nm
- IR cut off: > 700nm
- Transmission of visible light: > 95%
- Transmission off band: < 0.1%
- Surface quality: 60/40 (MIL-O-13830)
- Surface polished: 1/4 wavefront
- Surface parallelism: < 30 seconds
Other Information
- Country of Manufacture: China
The ideal luminance (UV/IR) filter for 36mm filter wheels.
This filter is unmounted; it doesn't have a metal ring.
The blackened edge of this filter helps reduce reflections and stray light, improving contrast and preventing unwanted artifacts in imaging applications.
Transmission
The following emission lines that are important for astrophotography are passing at > 95%.
- Hydrogen Alpha (H-Alpha): 656nm
- Sulphur II (SII): 672nm
- Nitrogen II (NII): 654nm and 658nm
Specifications
- Diameter: 3mm
- Edge treatment: Blackened
- Physical thickness: 1.85mm
- UV cut off: < 400nm
- IR cut off: > 700nm
- Transmission of visible light: > 95%
- Transmission off band: < 0.1%
- Surface quality: 60/40 (MIL-O-13830)
- Surface polished: 1/4 wavefront
- Surface parallelism: < 30 seconds
The ideal luminance (UV/IR) filter for 36mm filter wheels.
This filter is unmounted; it doesn't have a metal ring.
The blackened edge of this filter helps reduce reflections and stray light, improving contrast and preventing unwanted artifacts in imaging applications.
Transmission
The following emission lines that are important for astrophotography are passing at > 95%.
- Hydrogen Alpha (H-Alpha): 656nm
- Sulphur II (SII): 672nm
- Nitrogen II (NII): 654nm and 658nm
Specifications
- Diameter: 3mm
- Edge treatment: Blackened
- Physical thickness: 1.85mm
- UV cut off: < 400nm
- IR cut off: > 700nm
- Transmission of visible light: > 95%
- Transmission off band: < 0.1%
- Surface quality: 60/40 (MIL-O-13830)
- Surface polished: 1/4 wavefront
- Surface parallelism: < 30 seconds
Other Information
- Country of Manufacture: China
| Product Status | new |
|---|---|
| Free Shipping Graphic | Free US Shipping |
| Hide Found a better Shipped Price on Frontend? | No |
OGMA 36mm Unmounted UV/IR Cut Filter
