Howie Glatter Holographic Attachment for Laser Collimator - Crosshair and Circle Scope Pattern (New Version)
- This item is out of stock.
- We have no ETA from the manufacturer at this time.
- Sign up for back-in-stock alerts to be notified when this item becomes available.
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available.
- This item is out of stock.
- We have no ETA from the manufacturer at this time.
- Sign up for back-in-stock alerts to be notified when this item becomes available.
Lower 48 States:
Orders over $50 ship free within the Lower 48 using a carrier and service we select based on your items and delivery location. Faster shipping options may be available at checkout.
U.S. Outside the Lower 48 (AK, HI, PR):
Free shipping on orders over $50 applies to many—but not all—items. Add items to your cart and enter your ZIP code to see available shipping options and any costs.
International Orders:
Free shipping does not apply to international orders. You’ll see available shipping options and costs during checkout. Some items can’t be shipped internationally due to size or manufacturer restrictions. Duties, taxes, brokerage fees, and tariffs are not included and are the customer’s responsibility.
Please Note:
- This is the new "NV" version and not the old version.
- New Version (this item): Bigger & coarser 3/8-32 thread diameter. Identified by a visible ring. Old Version (no longer available from Agena): Super fine 5/16-56 thread diameter. No visible ring
- If you plan to use one of their holographic attachments such as this item, you need to make sure that you match the "old" Howie Glatter collimator with the "old" holographic attachment, and the "NV" collimator with the "NV" holographic attachment.
Optional holographic attachments for Howie Glatter laser collimators screw into the laser aperture and have a white screen front surface. They contain an optical element that diffracts most of the laser light into a diverging symmetrical pattern around the central beam. The projected pattern is useful for centering optical elements by making it symmetrical with the edge of the optic.
A cross-hair and circle “scope” pattern is available that spans 10 degrees. It has utility for non-Barlowed , conventional Newtonian primary collimation, where the primary is adjusted to return the reflected central laser beam back into the laser aperture of the collimator. The cross-hair intersection makes it easier to see when the return beam is centered on the collimator face.
This item is meant for use ONLY with compatible Howie Glatter laser collimators. It cannot be used with collimators from any other brand.
Other Information
- Country of Manufacture: United States
Please Note:
- This is the new "NV" version and not the old version.
- New Version (this item): Bigger & coarser 3/8-32 thread diameter. Identified by a visible ring. Old Version (no longer available from Agena): Super fine 5/16-56 thread diameter. No visible ring
- If you plan to use one of their holographic attachments such as this item, you need to make sure that you match the "old" Howie Glatter collimator with the "old" holographic attachment, and the "NV" collimator with the "NV" holographic attachment.
Optional holographic attachments for Howie Glatter laser collimators screw into the laser aperture and have a white screen front surface. They contain an optical element that diffracts most of the laser light into a diverging symmetrical pattern around the central beam. The projected pattern is useful for centering optical elements by making it symmetrical with the edge of the optic.
A cross-hair and circle “scope” pattern is available that spans 10 degrees. It has utility for non-Barlowed , conventional Newtonian primary collimation, where the primary is adjusted to return the reflected central laser beam back into the laser aperture of the collimator. The cross-hair intersection makes it easier to see when the return beam is centered on the collimator face.
This item is meant for use ONLY with compatible Howie Glatter laser collimators. It cannot be used with collimators from any other brand.
Please Note:
- This is the new "NV" version and not the old version.
- New Version (this item): Bigger & coarser 3/8-32 thread diameter. Identified by a visible ring. Old Version (no longer available from Agena): Super fine 5/16-56 thread diameter. No visible ring
- If you plan to use one of their holographic attachments such as this item, you need to make sure that you match the "old" Howie Glatter collimator with the "old" holographic attachment, and the "NV" collimator with the "NV" holographic attachment.
Optional holographic attachments for Howie Glatter laser collimators screw into the laser aperture and have a white screen front surface. They contain an optical element that diffracts most of the laser light into a diverging symmetrical pattern around the central beam. The projected pattern is useful for centering optical elements by making it symmetrical with the edge of the optic.
A cross-hair and circle “scope” pattern is available that spans 10 degrees. It has utility for non-Barlowed , conventional Newtonian primary collimation, where the primary is adjusted to return the reflected central laser beam back into the laser aperture of the collimator. The cross-hair intersection makes it easier to see when the return beam is centered on the collimator face.
This item is meant for use ONLY with compatible Howie Glatter laser collimators. It cannot be used with collimators from any other brand.
Other Information
- Country of Manufacture: United States
